Lead Acid Battery Recycling Machine
Lead Acid Battery Recycling Machine is also called “lead acid battery recycling plant” or “lead acid battery recycling Equipment”. Lead Acid Battery Recycling Equipment is suitable for recycling all kinds of used lead-acid batteries, such as automotive battery, car batteries, truck battery, electric bicycle battery, etc.
Product Description
Lead Acid Battery Recycling Machine raw material can be processed is all kind of lead acid battery. Lead acid battery is very common battery, mostly used in the daily life. The final products of separation section is plastic, lead, acid.
Raw Materials
Used Lead Acid Batteries
Electric Bicycle Batteries
Electric Car Batteries
Car Batteries
Lead Acid Battery Recycling Equipment processes raw materials: Used lead-acid batteries, Car batteries, Electric car batteries, Electric bike batteries, etc.
Final Product
Pure Lead or Lead Alloy
Crude Lead
Plastic Granules
Plastic
Lead Battery Recycling Machine Final product: Scrap lead acid battery will be separated by the “Lead acid battery dismantling equipment”. The final products of separation section is plastic, lead, acid. After smelting and refining process, will get pure lead or lead alloy. And plastic also be reused after granulation.
Flow Chart
Used Lead Battery Recycling Process：
The Recycling process of Used Lead Acid Batteries can be categorized to 3 stages :
①Battery disassembly, crushing and separation
There are two options for battery disassembly, crushing and separation: using a lead-acid battery disassembly machine or using a lead-acid battery crushing and Separation line. After disassembly by the lead-acid battery disassembly line or after crushing and Separation, the lead paste, plastic (PP, PE, ABS), lead column and acid are finally separated.
②Smelting Furnace Process
After the separation, will get different kind of lead contend raw material, before smelting, need to do mixed at first, then will transfer to smelting furnace by vibrating screen. After smelting, release lead liquid to crucibles. During machine working, here will have pulse dust collector to collect dust and flue dust.
③Refining Furnace Process
After the smelting process, will get the crude lead, purity is about 95-96%, if want to get higher purity, need do the refining process. Need put crude lead to the refining furnace, then after process will get the purity is 99.9%. Also the finished product can be lead alloy.
Technical Parameter
Lead Acid Battery Recycling Machine Technical Parameters
Working voltage can be customized, and if you have other requrement and want to know more details, please contact us.(The data in this table are for reference only)
| Model | Capacity tons/day | Power/kw | Space Size |
| LABR-50 | 50tons/day | 300kw | 2000m2 |
| LABR-100 | 100tons/day | 500kw | 3000m2 |
| LABR-300 | 300tons/day | 800kw | 6000m2 |
| LABR-500 | 500tons/day | 1000kw | 15000m2 |
| LABR-1000 | 1000tons/day | 1500kw | 20000m2 |
Product advantages
Advantages of Our Lead Acid Battery Recycling Equipment
Our lead acid battery recycling equipment boasts several key advantages:
1. Efficiency and Productivity: Our lead acid battery recycling machine is designed for high throughput, ensuring maximum yield with minimal energy consumption.
2. Cost-Effectiveness: Our lead acid battery recycling machine offers a quick return on investment through revenue from recycled materials and reduced disposal fees.
3. Customization: We offer tailored solutions to meet specific client requirements.
Guanma Machinery Lead Recycling Plant Manufacturer provides from plant design and installation to maintenance and technical support in lead battery recycling business. How much does a lead acid battery recycling plant cost? Contact us today to get a quote!
